- 802.11n connectivity for increased network capacity

    - Up to 300 Mbps wireless speeds

    - White rugged metal plenum-rated chassis to meet fire regulations

    - Four products in one: Access Point, Wireless Client, WDS, WDS with AP

    - 1 Gigabit Ethernet port for the fastest wired speeds

    - Power over Ethernet (PoE) support for convenient installation

    - Multiple SSID for wireless network segmentation

    - AP Array feature to help IT administrators quickly deploy a multi-point wireless network

    - Load Balancing function to optimise high network traffic volume and redundancy

    - VLAN support

    - WMM™ (Wireless Multi Media) to prioritise audio, video and voice applications

    - Enhanced security with RADIUS support

    - High power radio design


Standards: IEEE 802.11n / IEEE 802.11g/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3u/ IEEE 802.3
Management: Telnet - Secure (SSH) Telnet/ Web Browser Interface/HTTP - Secure HTTP (HTTPS)/SNMP Support/D-View Module - Private MIB/AP Manager II/AP Array
Security: WPA™ - Personal/WPA2™ - Enterprise/WPA2™ - Personal/WPA2™ - Enterprise/64/128-bit WEP/SSID Broadcast Disable/MAC Address Access Control/Rogue AP Detection
VLAN: 802.1q VLAN support
SSID Support: Multiple (up to 8 SSID)
Quality of Service (QoS)
    - 4 Priority Queues

    - WMM Wireless Priority

Wireless Frequency Range: 2.4 GHz to 2.4835 GHz
Operating modes
    - Access Point (AP)

    - WDS with AP

    - WDS/Bridge (No AP Broadcast)

    - Wireless Client

Dipole Antenna Gain: 5 dBi @ 2.4 GHz
Maximum Transmit Output Power: FCC : 26 dBm / ETSI : 14 dBm (Dual Chain)
Maximum Power Consumption
    - 9 watts with PoE

    - 8 watts without PoE

Power Supply: 5 V/2.5 A or PoE
Weight: 768 g.
Dimensions (W x H x D): 166 x 188 x 37 mm
